Specifications

Video Doorbell

1/2.8” Progressive CMOS

4MP (2560 x 1440 pixel)

Night Vision: 5m(16.5ft) Distance

2.3 mm Fixed Lens, 30°Pan

Field of View : 125°(H), 98°(D), 166°(D)

6000mAh Rechargeable Battery

Auxiliary Interface

Video Doorbell:

Built-in Mic & Speaker

Power On / Off Button

Chime:

Micro SD Card Slot (up to 512GB)

Built-in Speaker

Reset Button

Video & Audio

Video Compression : H.265

Up to 15fps Frame Rate

Two-way Talk

8x Digital Zoom

General

Video Doorbell:

Charging Power: DC 5V 1A, Type-C Port

Optional Hardwired Power Supply (8~24VAC, ≥5VA)

Power Consumption: up to 2.27W

Working Environment:-20°C~+50°C, Less Than 95%RH

Charging Temperature:0°C~+45°C

Dimensions: 150 × 55 × 50.3 mm (5.9× 2.2 × 2.0 inch)

Weight: 237.5g (0.5 lb)

CE, Weatherproof

Chime:

AC Power Supply: 100~240 VAC

Power Consumption: up to 3W

Working Environment:-10°C~+45°C, Less Than 95%RH

Dimensions: 95.5 × 65.1 × 30.2mm

(3.8× 2.6 × 1.2 inch)

Weight: 79g (0.2 lb)

CE

Notice Management

Doorbell Call Notification

PIR Motion Detection

Loitering Detection

Auto Power Saving Mode

Network

Wi-Fi:IEEE802.11b/g/n, 2.4GHz

Chime works as the Wi-Fi extender for the Doorbell

imou App: iOS, Android

What’s in the box

- 1x Doorbell

- 1x Quick Start Guide

- 1x Surface Mounting Bracket

- 1x USB Charging Cable

- 3x Wire Nuts

- 2x 3M Glue

- 1x Chime Plug

- 1x Screw Package

- 1x Pin

- 1x Installation Position Map

- 2x Extension Wire

- 1x Jumper Wire

- 1x Chime
